Everything in detail

All-New RAV4 Icon specifications

View specifications

Space and Room

High-quality fabrics and soft ornamentation add pleasingly human touches to your interior, transforming the open cabin into an inviting space where everyone feels comfortable.

Exterior dimensions

Exterior Length (mm): 4600 mm
Exterior Width (mm): 1855 mm
Exterior Height (mm): 1685 mm
Front Tread (mm): 1600 mm
Rear Tread (mm): 1630 mm
Overhang Front (mm): 920 mm
Overhang Rear (mm): 990 mm
Wheelbase (mm): 2690 mm

Interior dimensions

Number of Seats: 5 seats
Interior length (mm): 1877 mm
Interior Width (mm): 1523 mm
Interior Height (mm): 1221 mm

Luggage volume

Load Volume (m³): 0.446 m³

Engine

Drive with pure emotion, powered by a high-performance engine that helps you take on any journey with confidence.

Environmental Performance

CO2 Combined - WLTP - Weighted (g/km): 30 g/km
Fuel Economy - Combined WLTP - Weighted (mpg): 217.2 mpg
Fuel Economy: 141.2 - 217.2 mpg
Fuel Economy - Combined WLTP - Weighted (l/100km): 1.3 l/100 km
Equivalent All Electric Range – Combined WLTP (miles): 85.13 miles
Electric Consumption (Wh/km): 155 Wh/km
Power Consumption WLTP (kWh/100 miles): 24.9 kWh/100 miles
Carbon Monoxide, CO (mg/km): 108.3 mg/km
Hydrocarbons, THC (mg/km): 12.5 mg/km
Hydrocarbons, NMHC (mg/km): 10 mg/km
Nitrogen Oxides, NOx (mg/km): 3.1 mg/km
Sound Level Drive By (dB(A)): 66.0 dB(A)
Euro Class: EURO 6 EB
Recommended Fuel Grade: 95 or more (octane)
Fuel Tank Capacity (l): 55 l
Electric Consumption Weighted (kWh/100miles): 19.6 kWh/100 miles
Electric Consumption Weighted (Wh/km): 122 Wh/km

Performance

Maximum Speed (mph): 111 mph
Acceleration 0-62 (mph): 7.5 seconds
Drag Coefficient (Cd): 0.346

Engine

Total System Output (DIN hp): 272 DIN hp
Total System Output (kW): 200 kW
Engine Code: a25a-fxs
Displacement (cc): 2487 cc
Bore x Stroke (mm x mm): 87.50 x 103.48 mm
Compression Ratio: 14:1
Engine Layout & Number Of Cylinders: 4-cylinder,in-line
Valve Mechanism: 16-valve dohc, chain drive (with vvt-ie and vvt-i)
Fuel Injection System: Fuel injection
Hybrid Vehicle Battery: Type: Lithium-ion
Hybrid Vehicle Battery: Capacity Ah (hr): 58.0 Ah
Maximum Torque (Nm): 272 Nm
10-80% Charging Time (mins) DC Charger: 28 mins (approx)
Maximum Charging Power AC (kW): 11 kW
Maximum Charging Power DC (kW): 50 kW
Battery Capacity (Ah): 58.0 Ah
Battery Capacity (kWh): 22.7 kWh
Electric Front Motor: Type: permanent magnet synchronous motor
Electric Front Motor: Maximum Voltage (V): 391 V

Transmission

Transmission Type: Automatic
Drive: FWD

Suspension

Suspension Front: Macpherson strut
Suspension Rear: Trailing wishbone

Brakes

Brakes Front: Ventilated disc 2- cylinder
Brakes Rear: Ventilated disc brake 1-cylinder

Weights & Towing Capacity

Gross Train Weight - Total (kg): 3330 kg
Gross Vehicle Weight (kg): 2530 kg
Kerb Weight / Unladen Weight (kg): 1895-1930 kg
Maximum Trailer Weight - Braked (kg): 800 kg
Maximum Trailer Weight - Unbraked (kg): 750 kg

Safety

Find peace of mind as you drive with Toyota T-Mate. Whether you’re reversing into a parking space or approaching a busy junction, T-Mate makes sure you're always in safe hands wherever you go.

Road Events
eCall emergency call system
Toyota Safety Sense
Pre-Collision System
Driver monitoring camera
Emergency Driving Stop system
Lane Trace Assist
Rear Cross Traffic Alert
Road Sign Assist
Adjustable Speed Limiter
Full-range Adaptive Cruise Control with ECO run mode
Tyre Pressure Warning system
Automatic headlight levelling
Automatic High Beam
LED daytime running lights
LED turning signal with day time running light integration
LED dual-beam Projector headlights
LED front fog lights
LED high mounted stop light
LED rear brake lights
LED rear combination lights
LED rear fog lamps
Indicators integrated on door mirrors
Automatic rear flashing hazard lights
Emergency brake-light signal
Safe Exit Assist
Blind Spot Monitor
Anti-lock Braking System with Electronic Brake force Distribution
Brake Assist
Vehicle Stability Control
Hill-start Assist Control
Reversing Camera
Intelligent clearance sonar (rear for objects, vehicle and Pedestrians)
Front Intelligent clearance sonar (with objects, vehicle and pedestrians detection)
Auto wipers
Immobiliser
Intrusion alarm
Intrusion sensor
Tilt detection sensors
Acoustic vehicle alert system
UV-filter on windshield

Passenger airbag on/off-switch
Driver & passenger central airbag
Driver & passenger front airbag
Front curtainshield airbag
Rear curtainshield airbag
Light reminder warning
ISOFIX child restraint system
Rear headrests (3-fixed)
Self power siren
Automatic door lock
Steering lock
Front seat belt reminder
Rear seat belt reminder
Pre-tensioners and force limiters
Rear seats occupant detection sensor
Passenger seat occupant detection sensor
Rear seat reminder system with sensor

Styling

Make a statement with elegant design elements and eye-catching details to make your vehicle stand out from the crowd.

Body-coloured upper front grille
Silver front under-run
Silver rear under-run
Black front bumper
Black rear bumper
Rear spoiler
Black wheel arch moulding
Privacy Glass on rear windows
Privacy glass on rear quarter windows
Body-coloured door handles
Black door mirrors
Chrome Toyota RAV4 badge on tailgate
Luggage compartment light

Black side air vent surrounds
Black side air vents
3-spoke leather steering wheel
Rear armrest
Synthetic leather front door armrests
Synthetic leather rear door armrests
Synthetic leather front door trim
Soft-touch front assist grips
Gunmetal interior door handles
Gloss black surround on multimedia display screen
Open tray on passenger dashboard

Performance

From road-ready handling to efficient acceleration – discover what makes the Toyota driving performance so special.

Drive mode selector (3 modes)
Auto EV/Hybrid mode
Dual exhaust pipes
Auto Limited Slip Differential lock

Wheels

Choose from Toyota's selection of premium wheels to suit your driving style.

Tyre Repair Kit (TRK)

Comfort

Sit back and relax in a car so comfortable that it feels like home – from ample space to stretch your legs to heating that keeps you warm when it's cold outside.

Auto-retractable door mirrors
Electric heated door mirrors
Smartphone remote door lock
Smartphone remote door locking operation
Smartphone hazard lights notification
Smartphone remote power window operation
Puddle lights
Electric fuel lid release with switch
Power tailgate
Standard charger (11kW AC)
Smartphone remote hazard lights system

12.3" Colour multi-information screen
Colour multi-information display
Digital speedometer (mph)
Analogue tachometer
ECO-driving Indicator
Hybrid system indicator
Dual-zone automatic air conditioning
Rear passenger air vents
Remote air conditioning system
Pollen air filter with deodorising odour eliminator
Clean air filter
Energy-safe airflow control (front)
Humidity sensor
Push-button start
Paddle shifts
Shift-by-wire with parking switch
Electric Power Steering
Heated steering wheel
Manual telescopic steering wheel
Manual tilt steering wheel
Audio switches on steering wheel
Voice recognition switch on steering wheel
UV-filter on driver & front passenger windows
Anti-jam protection on power windows
Rear window defogger
Rear window wiper
Intermittent rear wiper
Auto-dimming rear view mirror
Adjustable lumbar support on driver seat
Manually height-adjustable front passenger seat
Power-height-adjustable driver seat
Heated driver & front passenger seats
60:40 split-folding 2nd row rear seats
Driver & front passenger adjustable headrest
Console box 12V power outlet
luggage compartment 12V power outlet
Driver & front passenger personal LED lights
Front footwell lights
Illuminated entry system
LED luggage compartment light
LED Centre room light
LED front room light
Rear passenger personal LED lights
Light on driver sun visor
Light on passenger sun visor
Mirror on driver sun visor
Mirror on passenger sun visor
Front overhead assist grips (2)
Assist grips - Rear (2)
Lights control system
Dynamic guide lines on reversing camera
Reversing camera display in multimedia system
Child safety door lock
Electronic parking brake

Multimedia

Experience an intuitive multimedia system that seamlessly delivers real-time information, making it easier than ever for you to focus on the road ahead.

Connected Services
12.9" multimedia display
12.9" Toyota Smart Connect+ multimedia system with wireless Smartphone integration incl Apple CarPlay™
Smartphone integration including Apple CarPlay™ & Android Auto™
Toyota navigation
Cloud navigation
Digital Audio Broadcast (DAB)
6 speakers
Bluetooth® Connectivity
Voice recognition
Smart voice assist
Microphone (2)
Aux-in connector
USB-C data connector in Centre console box
Front USB-C connectors x 2
Rear USB-C connectors x 2

Storage

This fantastic interior space offers plenty of room for all ‒ including ample legroom to comfortably stretch your legs, and a spacious boot to fit everything you’ll need.

Aluminium roof rails
Pre-wiring for towing hook
Front towing hook (1)
Rear towing hook (1)

Protection

The world places a lot of demand on your car, from rock chips and paint scratches to everyday weathering. Take care of the vehicle that drives your future with a protection package.

Driver & front passenger floor mats with heel pads
