Change model

RAV4 Plug-in Dynamic
Features & Specs

5 Door SUV

The Dynamic grade Plug-in Hybrid represents an uncompromising statement and style.
RAV4 Plug-in - Dynamic - 5 Door SUV
Obsidian Blue Bi-tone (Metallic Paint)

Starting from

45755.0

Financing From

£ 597.81/Month

*Representative Example and Core Finance Terms

Standard Engine

2.5 Petrol Hybrid AWD-i (306hp)

Warranty

Up to 10 years / 100,000 mile Toyota Warranty*

RAV4 Plug-in - Dynamic - 5 Door SUV

https://dxp-webcarconfig.toyota-europe.com/v1/compare-v2/gb/en

  • Front Tread (mm)
    1600 mm
  • Overhang Front (mm)
    910 mm
  • Overhang Rear (mm)
    1000 mm
  • Exterior width (mm)
    1855 mm
  • Exterior length (mm)
    4600 mm
  • Rear Tread (mm)
    1630 mm
  • Wheelbase (mm)
    2690 mm
  • Exterior height (mm)
    1690 mm
  • Load volume (m³)
    0.52 m³
  • 2 seat mode (laden to roof)
    1604 litres
  • 5 seat mode (laden to roof)
    657 litres
  • Luggage Capacity (laden to tonneau cover) l
    520 litres
  • Luggage Capacity (rear seats down, laden to roof)
    1604 litres
  • Climbing Angle (°)
    18 °
  • Min. running ground clearance (mm)
    190 mm
  • Wading depth (mm)
    500 mm
  • Limit angle of vehicle turnover (°)
    52 °
  • Ramp break-over angle (°)
    16.4 °
  • Departure Angle (°)
    20 °
  • Limit angle of vehicle turn over
    52 °
  • Approach Angle (°)
    17.5 °

  • Sound Level Drive by (dB(A))
    64.0 dB(A)
  • Nitrogen Oxides, NOx (mg/km)
    4.2 mg/km
  • Fuel Economy - Combined Min WLTP (mpg)
    282.4 mpg
  • CO2 Combined WLTP (g/km)
    22 g/km
  • CO2 Combined WLTP - Max (g/km)
    22 g/km
  • Fuel tank capacity
    55 l
  • Hydrocarbons, NMHC (mg/km)
    11.5 mg/km
  • Carbon monoxide, CO (mg/km)
    126.1 mg/km
  • Fuel Grade - recommended
    95 or more
  • Fuel Economy - Combined Max WLTP (mpg)
    282.4 mpg
  • Euro class
    EURO 6 AP
  • Hydrocarbons, THC (mg/km)
    13.3 mg/km
  • Hybrid vehicle battery: Type
    Lithium-ion Battery
  • Bore x Stroke (mm x mm)
    87.50 x 103.48 mm
  • Electric Front Motor: Maximum torque (Nm)
    270 Nm
  • Maximum output (DIN hp)
    306 DIN hp
  • Hybrid vehicle battery: Capacity Ah (hr)
    51 Ah
  • Valve Mechanism
    16-Valve DOHC, VVT-iE (Intake), VVT-i (Exhaust)
  • Number of Cylinders
    4 CYLINDER, IN LINE
  • Electric Front Motor: Type
    Permanent magnet synchronous motor
  • Total hybrid system output (kW)
    225 kW
  • Hybrid vehicle battery: Number of modules
    96
  • Engine Code
    A25A-FXS
  • Compression Ratio
    14.01:1
  • Total hybrid system output (DIN hp)
    306 DIN hp
  • Maximum torque (Nm@rpm)
    227/3200-3700 Nm@rpm
  • Displacement (cc)
    2487 cc
  • Fuel Injection System
    FUEL INJECTION
  • Electric Front Motor: Maximum output (kW)
    134 kW
  • Maximum output (kW@rpm)
    225 kW@rpm
  • Transmission Type
    Automatic
  • Acceleration 0-62 (mph)
    6 seconds
  • Maximum Speed (mph)
    111 mph
  • Suspension Front
    MACPHERSON STRUT
  • Suspension Rear
    DOUBLE WISHBONE
  • Brakes Front
    VENTILATED DISC 2-CYLINDER
  • Brakes Rear
    VENTILATED DISC 1-CYLINDER
  • Maximum Trailer Weight - Unbraked (kg)
    750 kg
  • Maximum Trailer Weight - Braked (kg)
    1500 kg
  • Kerb Weight / Unladen Weight (kg)
    1930-1995 kg
  • Gross Vehicle Weight - Total (kg)
    2510 kg
  • Gross Train Weight - Total (kg)
    4010 kg
  • Gross Vehicle Weight - Front (kg)
    1265 kg
  • Gross Vehicle Weight - Rear (kg)
    1315 kg
  • Number of Seats
    5 seats
  • Interior height (mm)
    1230 mm
  • Interior width (mm)
    1515 mm
  • Interior length (mm)
    1890 mm
  • Turning Radius tyre (m)
    5.7 m

Legend
  • Standard
  • Optional
  • Not applicable
  • Promotion
  • Exception
  • Available in optional pack
Interior
  • Toyota Touch® 2 with Go Navigation
  • 9" Toyota Touch® 2 multimedia system with Smartphone integration incl Apple CarPlay™ & Android Auto™
  • 6 speakers
  • Bluetooth® Connectivity
  • Digital Audio Broadcast (DAB)+
  • MyT Connected Services
  • USB connectors - Front armrest
  • USB connector - Rear
Exterior
  • Black roof rails
Interior
  • 1.5 litre bottle holder
  • Boot underfloor storage
  • Coats hooks - 2 rear
  • Driver & passenger seatback pockets
  • Front bottle holders
  • Front cup holders
  • Lockable glovebox
  • Rear bottle holders
  • Rear console box
  • Rear cup holders
  • Retractable tonneau cover
  • Sunglasses holder
Exterior
  • Tyre Repair Kit (TRK)
  • 19" Black Machined-face alloy wheels (5-spoke)
Exterior
  • Smart Entry & Push-button start
  • Auto headlights
  • Auto wipers
  • Auto-retractable door mirrors
  • Boot door release with Push-button
  • Power-adjustable door mirrors
  • Electric heated door mirrors
  • Follow-me-home headlights
  • Power back door
  • Puddle lights
  • Remote boot door release in cabin
  • Remote door lock
  • Remote tailgate release on key
  • 7.5m cable with home charging plug
  • Fast Charge 32A Mennekes cable
Interior
  • Push-button start
  • 12v power outlet - Boot
  • 12v power outlet - Front
  • 220v power socket - Boot
  • 60:40 split-folding rear seats
  • Adaptive Cruise Control (ACC) switch on steering wheel
  • Adjustable Speed Limiter (ASL) switch on steering wheel
  • Anti-jam protection on power windows
  • Assist grips - Front
  • Assist grips - Rear
  • Audio switches on steering wheel
  • Automatic High Beam (AHB) on/off switch
  • Central armrest
  • Child safety door lock
  • Clean air filter
  • Dynamic guide lines on Reversing Camera
  • Front power windows
  • Electric Power Steering (EPS)
  • Auto up & down function on power windows
  • Front footwell lights
  • Heated driver & front passenger seats
  • Heated outer rear seats
  • Illuminated entry system
  • Lane Departure Alert (LDA) switch on steering wheel
  • Light on driver sun visor
  • Light on passenger sun visor
  • Manual telescopic steering wheel
  • Manual tilt steering wheel
  • Manually reclining front passenger seat
  • Manually sliding front passenger seat
  • Mirror on driver sun visor
  • Mirror on passenger sun visor
  • Multimedia switches on steering wheel
  • Pollen air filter
  • Power-adjustable lumbar support on driver seat
  • Power-height-adjustable driver seat
  • Power-reclining driver seat
  • Power-sliding driver seat
  • Rear door armrests
  • Rear passenger air vents
  • Rear power windows
  • Rear window defogger
  • Rear window wiper
  • Reclining rear seats
  • Speed-detecting automatic door lock
  • Telephone switches on steering wheel
  • Toyota Easy Flat system
  • Voice recognition switch on steering wheel
  • Wireless mobile phone charger
  • Electrochromatic auto-dimming rear view mirror
  • Remote Controlled Dual-zone automatic air conditioning
  • 7" multi-information screen
  • Driver & front passenger personal LED lights
  • LED Boot light
  • LED Centre room light
Exterior
  • Front parking sensors
  • Rear parking sensors
  • Reversing Camera
  • Pre-Collision System with Day & Night-time Pedestrian and Cyclist Detection
  • Lane Departure Alert (LDA) with Steering Control
  • Automatic High Beam (AHB)
  • Intelligent Adaptive Cruise Control
  • Adjustable Speed Limiter (ASL)
  • Anti-lock Braking System (ABS) with Electronic Brake force Distribution (EBD)
  • Blind Spot Monitor (BSM)
  • Brake Assist (BA)
  • Driver Attention Alert
  • eCall emergency call system
  • Emergency Brake-light Signal (EBS)
  • Glass-breaking alarm sensors
  • Hill-start Assist Control (HAC)
  • Immobiliser
  • Indicators integrated on door mirrors
  • Intrusion Alarm
  • Lane Trace Assist
  • LED Daytime running lights
  • LED Dual-beam Projector headlights
  • LED High mounted stop light
  • LED Rear brake lights
  • Memory on speed limiter
  • Motion sensor alarm
  • Rear Cross Traffic Alert (RCTA)
  • Tilt detection sensors
  • Trailer Sway Control (TSC)
  • Tyre Pressure Monitoring System (TPMS)
  • Vehicle Stability Control (VSC)
  • LED Front fog lights
  • LED Indicators
Interior
  • Supplemental Restraint System (SRS) airbags - 7 airbags
  • Adjustable Driver seat belt extender
  • Adjustable Front Passenger seat belt extender
  • Driver & front passenger Whiplash Injury Lessening (WIL) seats
  • Front passenger airbag detector
  • Front seat belt reminder
  • ISOFIX child restraint system
  • Passenger airbag on/off-switch
  • Pre-tensioners and force limiters
  • Rear headrests (3)
  • Rear seat belt reminder
Exterior
  • Dual exhaust pipes
  • Drive mode selector
Interior
  • Floor mats
Exterior
  • Black door moulding
  • Black painted upper front grill
  • Black rear under-run
  • Body-coloured door handles
  • LED Front light guide
  • LED Rear light guide
  • Privacy Glass
  • Black shark-fin antenna
  • Black door mirrors
  • Black rear spoiler
  • Black Bi-tone roof
  • Black front bumper
  • Black rear bumper
  • Honeycomb upper front grille
  • Black surrounds on front fog lights
  • Black front under-run
Interior
  • 3-spoke Leather steering wheel
  • Black centre air vent surround
  • Black centre console
  • Black lower passenger dashboard
  • Black roof lining
  • Black side air vents
  • Black upper dashboard
  • Electronic parking brake
  • Framed rear view mirror
  • Leather gear shift
  • Blue ambient lighting on front cup holders
  • Blue ambient lighting on open tray
  • Open tray on passenger dashboard
  • Rear armrest
  • Satin chrome interior door handles
  • Silver gear shift surround on centre console
  • Silver insert on upper dashboard
  • Soft-touch texture on lower dashboard
  • Soft-touch texture on upper dashboard

  • 2690
  • 4600
  • 1600
  • 1855
  • 1630
  • 1855
  • 1690
  • Exterior length (mm) 4600 mm
  • Exterior width (mm) 1855 mm
  • Exterior height (mm) 1690 mm
  • Front Tread (mm) 1600 mm
  • Rear Tread (mm) 1630 mm
  • Overhang Front (mm) 910 mm
  • Overhang Rear (mm) 1000 mm
  • Wheelbase (mm) 2690 mm

  • interior-image0
  • interior-image1
  • interior-image2
  • Number of Seats 5 seats
  • Interior length (mm) 1890 mm
  • Interior width (mm) 1515 mm
  • Interior height (mm) 1230 mm

  • Luggage Capacity (laden to tonneau cover) l 520 litres
  • Luggage Capacity (rear seats down, laden to roof) 1604 litres
  • 5 seat mode (laden to roof) 657 litres
  • 2 seat mode (laden to roof) 1604 litres
  • Load volume (m³) 0.52 m³

Standard equipment

Build

From intelligent safety systems to intuitive interior features, every Toyota leaves the factory with a wealth of essential equipment as standard. Find out more about the standard equipment available on your Toyota vehicle below:

Tyre Repair Kit (TRK)
19" Black Machined-face alloy wheels (5-spoke)

https://dxp-webcarconfig.toyota-europe.com/v1/equipment-standard/gb/en?modelId=61c17908-5693-4b02-b49e-96c0e527f2e7&carId=d6fe7a6d-6c58-42d9-b8ec-3616ffe456da&carColourId=35b43a17-f341-427e-831f-0d2c1d7d5a95&contentViewMode=list

Ready to start? Choose your engine
Ready to start? Choose your engine

1 Options

1 Options

  • 2.5 Petrol Hybrid AWD-i (306hp) Hybrid Electric

    Automatic | Intelligent All Wheel Drive

    More details Collapse

    282.4 - 282.4 (mpg)

    Fuel Economy

    22 - 22 (g/km)

    WLTP CO2

    More details Collapse

Choose your RAV4 Plug-in
Choose your RAV4 Plug-in

2 Options

2 Options

  • Design

    5 Door SUV

    from 44140.0

    • 18" Grey Machined-face alloy wheels (5-spoke)
    • 9" Toyota Touch® 2 multimedia system with Smartphone integration incl Apple CarPlay™ & Android Auto™
    • Remote Controlled Dual-zone automatic air conditioning
    • Fast Charge 32A Mennekes cable
    • Pre-Collision System with Day & Night-time Pedestrian and Cyclist Detection
    • Rear Cross Traffic Alert (RCTA)
    • Power back door
    • Heated outer rear seats

    More details Collapse

  • Dynamic

    5 Door SUV

    from 45755.0

    • 19" Black Machined-face alloy wheels (5-spoke)
    • Black Bi-tone roof
    • Wireless mobile phone charger
    • Fast Charge 32A Mennekes cable
    • 9" Toyota Touch® 2 multimedia system with Smartphone integration incl Apple CarPlay™ & Android Auto™
    • Remote Controlled Dual-zone automatic air conditioning
    • Power back door
    • Heated outer rear seats

    More details Collapse

Start Building Your RAV4 Plug-in

Build your perfect RAV4 Plug-in - save for later, send to a dealer or buy directly online.
Start building now

CHOOSE FROM A RANGE OF FINANCE OPTIONS
