Everything in detail

Proace Verso Icon specifications

View specifications

Space and Room

High-quality fabrics and soft ornamentation add pleasingly human touches to your interior, transforming the open cabin into an inviting space where everyone feels comfortable.

Exterior dimensions

Exterior Length (mm): 4981 mm
Exterior Width (mm): 1924 mm
Exterior Height (mm): 1910 mm
Front Tread (mm): 1630 mm
Rear Tread (mm): 1618 mm
Overhang Front (mm): 904 mm
Overhang Rear (mm): 803 mm
Wheelbase (mm): 3275 mm

Interior dimensions

Number of Seats: 8 seats
Interior length (mm): 3161 mm
Interior Width (mm): 1515 mm

Luggage volume

Luggage Capacity (Laden To Roof): 700 litres
7 Seat Mode (Laden To Tonneau Cover): 507 litres
7 Seat Mode (Laden To Roof): 655 litres
5 Seat Mode (Laden To Tonneau Cover): 950 litres
5 Seat Mode (Laden To Roof): 1600 litres
2 Seat Mode (Laden To Tonneau Cover): 1800 litres
2 Seat Mode (Laden To Roof): 2700 litres
Load Volume (m³): 0.55 m³
VDA luggage capacity, rear seat up (liters): 550 litres

Electric Engine

Electric Engine description

Environmental Performance

WLTP CO2: 0 g/km
Fuel Economy: 0 mpg
Pure Electric Range – Combined WLTP (km): 344 km
Electric Range: 194.49 - 213.75 miles
Electric Consumption (Wh/km): 242 Wh/km
Power Consumption WLTP (kWh/100 miles): 38.9 kWh/100 miles
Sound Level Drive By (dB(A)): 67.0 dB(A)
Euro Class: AX

Performance

Maximum Speed (mph): 82 mph

Engine

Total System Output (kW): 100 kW
Maximum Output (DIN hp): 136 DIN hp
Maximum Output (kW@rpm): 100/ kW@rpm
Maximum Torque (Nm@rpm): 260 Nm
Hybrid Vehicle Battery: Capacity Ah (hr): 187.5 Ah
Hybrid Vehicle Battery: Number Of Modules: 27
Total Number Of Cells In Battery Pack: 324
Battery Capacity (Usable, kWh): 69 kWh
Rapid charging time 10-80%: 45 mins (approx)
0-100% Charging Time AC (hours): 11.3 hours (approx)
Battery Charging Time (hours) AC Charger: 11.3 hours (approx)
Maximum Charging Power AC (kW): 11 kW
Maximum Charging Power DC (kW): 100 kW
Battery Capacity (Ah): 187.5 Ah
Battery Capacity (kWh): 75 kWh
Battery Energy (kWh): 75 kWh
Battery Weight (kg): 534 kg
Electric Front Motor: Type: ZAE synchronous with permanent magnet / 4 pairs
Electric Front Motor: Maximum Output (kW): 100 kW
Electric Front Motor: Maximum Torque (Nm): 260 Nm

Transmission

Transmission Type: Automatic
Drive: FWD

Suspension

Suspension Front: Pseudo McPherson with anti-roll bar
Suspension Rear: Oblique Wishbone Trailing Arms

Brakes

Brakes Front: Ventilated Disc
Brakes Rear: Disc

Weights & Towing Capacity

Gross Train Weight - Total (kg): 4100 kg
Gross Vehicle Weight (kg): 3100 kg
Kerb Weight / Unladen Weight (kg): 2136-2457 kg
Maximum Trailer Weight - Braked (kg): 1000 kg
Maximum Trailer Weight - Unbraked (kg): 750 kg
Gross Vehicle Weight - Front (kg): 1500 kg
Gross Vehicle Weight - Rear (kg): 1650 kg

Safety

Find peace of mind as you drive with Toyota T-Mate. Whether you’re reversing into a parking space or approaching a busy junction, T-Mate makes sure you're always in safe hands wherever you go.

Anti-tamper alarm
Automatic High Beam
Cruise Control
Driver Attention Alert
Front fog lights
Glass-breaking alarm sensors
Hill-start Assist Control (HAC)
Intrusion Alarm
Lane Departure Alert (LDA)
LED Daytime running lights
LED Headlights
Motion sensor alarm
Pre-Collision System with Pedestrian Detection
Rear parking sensors
Tyre Pressure Warning System (TPWS)
Speed limiter with Road Sign Assist (RSA)
Driver Monitoring Camera
Intelligent Speed Assist
eCall emergency call system

ISOFIX child restraint system
Supplemental Restraint System (SRS) airbags - 6 airbags
Driver & passenger front airbag

Styling

Make a statement with elegant design elements and eye-catching details to make your vehicle stand out from the crowd.

Body-coloured door handles
Body-coloured front bumper
Body-coloured rear bumper
Chrome insert on upper front grille
Privacy Glass - 70% (Midnight tint)
Silver surround on lower front grille
Silver surrounds on front fog lights
Body-coloured rail cover on side sliding door
Black painted door mirrors

3-spoke Urethane steering wheel
Chrome interior door handles
Chrome side air vent surrounds
Chrome centre air vent surround
Palladium insert on dashboard
Palladium deco line on front door trim
Black rear interior door handles

Wheels

Choose from Toyota's selection of premium wheels to suit your driving style.

Full size Temporary spare wheel

Comfort

Sit back and relax in a car so comfortable that it feels like home – from ample space to stretch your legs to heating that keeps you warm when it's cold outside.

Auto headlights
Electric heated door mirrors
Power retractable door mirrors
Rear tailgate
Rear tailgate with fixed window
Remote door lock
Two fixed side windows on second row
Two sliding side doors

1/3 : 2/3 split-folding 2nd row rear seats
1/3 : 2/3 split-folding 3rd row rear seats
12v power outlet - Boot
12v power outlet - Front
2nd row 3-seat rear bench
2nd row rear passenger room light
3rd row 3-seat rear bench
3rd row rear passenger room light
Adjustable lumbar support on driver seat
Audio switches on steering wheel
Auto-dimming rear view mirror
Boot light
Colour multi-information display
Driver & front passenger personal lights
Drivers armrest
Front power windows
One touch auto up & down function on power windows
Electronic parking brake
Forward tilting 2nd row rear seats
Forward tilting 3rd row rear seats
Front passenger armrest
Front room light
Height-adjustable driver seat
Individual front passenger seat
Key starting system
Manual air conditioning
Manually reclining driver seat
Manually sliding driver seat
Noise reduction layer on front windows
Power child safety door lock
Power door lock
Rear passenger air conditioning
Rear passenger air vents
Rear passenger personal lights (2nd row)
Rear passenger personal lights (3rd row)
Rear window defogger
Rear window wiper
Speed Limiter Information
Upright folding 2nd row rear seats
Upright folding 3rd row rear seats
Cruise Control switch behind steering wheel
Windscreen de-icer
10" screen for multi-information display

Multimedia

Experience an intuitive multimedia system that seamlessly delivers real-time information, making it easier than ever for you to focus on the road ahead.

8 speakers
Toyota Touch® 2 with Go Navigation
Digital Audio Broadcast (DAB)
USB Type-C connector
10" Toyota Smart Connect with Smartphone integration including Apple CarPlay™
Toyota Smart Connect with Smartphone integration including Apple CarPlay™ Multimedia system
