Everything in detail

Proace Max Chassis Cab specifications

View specifications

Space and Room

High-quality fabrics and soft ornamentation add pleasingly human touches to your interior, transforming the open cabin into an inviting space where everyone feels comfortable.

Exterior dimensions

Exterior Length (mm): 5943 mm
Exterior Width (mm): 2050 mm
Exterior Height (mm): 2254 mm
Front Tread (mm): 1810 mm
Rear Tread (mm): 1790 mm
Overhang Front (mm): 948 mm
Overhang Rear (mm): 960 mm
Wheelbase (mm): 4035 mm

Interior dimensions

Number of Seats: 3 seats

Engine

Drive with pure emotion, powered by a high-performance engine that helps you take on any journey with confidence.

Environmental Performance

CO2 Combined - WLTP (g/km): 262 g/km
Fuel Economy: 24.3 - 28.2 mpg
Hydrocarbons, THC & Nitrogen Oxides, NOx (mg/km): 48.7 mg/km
Nitrogen Oxides, NOx (mg/km): 46.4 mg/km
Sound Level Drive By (dB(A)): 71.0 dB(A)
Euro Class: EURO 6 EB
Carbon Monoxide, CO (mg/km): 31 mg/km

Performance

Maximum Speed (mph): 96 mph

Engine

Displacement (cc): 2184 cc
Bore x Stroke (mm x mm): 83.8 x 99 mm
Compression Ratio: 15.5:1
Number Of Cylinders: 4 cylinder, in line
Maximum Output (DIN hp): 140 DIN hp
Maximum Output (kW@rpm): 103 kW@rpm
Maximum Torque (Nm@rpm): 350 Nm

Transmission

Transmission Type: Manual
Drive: FWD

Suspension

Suspension Front: Independent, MacPherson type (wishbones, coil springs, telescopic shock absorbers & anti-roll bar)
Suspension Rear: Rigid tubular axle(parabolic longitudinal leaf springs,telesc. shock absorbers,flexible side buffers

Brakes

Brakes Front: Disc
Brakes Rear: Disc

Weights & Towing Capacity

Gross Train Weight - Total (kg): 6500 kg
Gross Vehicle Weight (kg): 3500 kg
Kerb Weight / Unladen Weight (kg): 1825-1992 kg
Maximum Trailer Weight - Braked (kg): 3000 kg
Maximum Trailer Weight - Unbraked (kg): 750 kg
Gross Vehicle Weight - Front (kg): 2100 kg
Gross Vehicle Weight - Rear (kg): 2400 kg

Safety

Find peace of mind as you drive with Toyota T-Mate. Whether you’re reversing into a parking space or approaching a busy junction, T-Mate makes sure you're always in safe hands wherever you go.

Anti-tamper alarm
Automatic High Beam (AHB)
Cruise Control
Driver Attention Alert
eCall emergency call system
Glass-breaking alarm sensors
Hill-start Assist Control (HAC)
Intrusion Alarm
Lane Departure Alert (LDA) with Steering Control
Lane Trace Assist (LTA)
Motion sensor alarm
Pre-Collision System with Pedestrian and Cyclist Detection
Projector halogen headlights
Rear combination lights
Spare wheel carrier (under body)
Tyre Pressure Warning System (TPWS)
Vehicle Stability Control Plus (VSC+)
Road Sign Assist (RSA)
Intelligent Speed Assist
Pre-disposition for breathalyser engine lock
Safety Data Recording

Front seat belt reminder
Handbrake
Rear seat belt reminder
Driver & passenger front airbag

Styling

Make a statement with elegant design elements and eye-catching details to make your vehicle stand out from the crowd.

Black front bumper
Black painted upper front grill
Roof antenna
Privacy Glass - 30% (Smoke tint)

Wheels

Choose from Toyota's selection of premium wheels to suit your driving style.

Black small centre caps
Full size Temporary spare wheel

Comfort

Sit back and relax in a car so comfortable that it feels like home – from ample space to stretch your legs to heating that keeps you warm when it's cold outside.

Auto headlights
Power-adjustable door mirrors
Electric heated door mirrors
Manually retractable door mirrors
Standard arm door mirrors

Audio switches on steering wheel
Boot light
Drivers armrest
Height-adjustable driver seat
Lane Departure Alert (LDA) switch on lower driver dashboard
Manual air conditioning
Manual day/night rear-view mirror
Manually adjustable lumbar support on driver seat
Monochrome multi-information display
Speedometer (mph)
Telephone switches on steering wheel
Without
3.5" multi-information screen
Deadlock on rear doors
Driver & front passenger fold-up table

Multimedia

Experience an intuitive multimedia system that seamlessly delivers real-time information, making it easier than ever for you to focus on the road ahead.

4 speakers
7" Pro Touch® multimedia system
Bluetooth® Connectivity
Digital Audio Broadcast (DAB)+
Radio

Storage

This fantastic interior space offers plenty of room for all ‒ including ample legroom to comfortably stretch your legs, and a spacious boot to fit everything you’ll need.

Electric converter box
