Everything in detail

Proace City Active specifications

View specifications

Space and Room

High-quality fabrics and soft ornamentation add pleasingly human touches to your interior, transforming the open cabin into an inviting space where everyone feels comfortable.

Exterior dimensions

Exterior Length (mm): 4403 mm
Exterior Width (mm): 1848 mm
Exterior Height (mm): 1880 mm
Front Tread (mm): 1548 mm
Rear Tread (mm): 1568 mm
Overhang Front (mm): 890 mm
Overhang Rear (mm): 726 mm
Wheelbase (mm): 2785 mm
Number of Doors: 5

Interior dimensions

Number of Seats: 3 seats
Interior length (mm): 3090 mm
Interior Width (mm): 1229 mm
Interior Height (mm): 1200 mm

Luggage volume

Deck Length (mm): 1817 mm
Deck Width (mm): 1527 mm
Deck Height (mm): 1200 mm
Load Volume With Smart Cargo (2 Seats, m³): 3.8 m³
Loading Length With Smart Cargo (2 Seats, mm): 3090 mm
Load Volume (m³): 3.3 m³

Engine

Drive with pure emotion, powered by a high-performance engine that helps you take on any journey with confidence.

Environmental Performance

WLTP CO2: 0 - 143 g/km
Fuel Economy - Combined Max WLTP (mpg): 51.3 mpg
Fuel Economy - Combined WLTP (l/100km): 5.5 l/100 km
Hydrocarbons, THC & Nitrogen Oxides, NOx (mg/km): 78 mg/km
Nitrogen Oxides, NOx (mg/km): 72.5 mg/km
Sound Level Drive By (dB(A)): 68.0 dB(A)
Euro Class: EURO 6 EB
Fuel Tank Capacity: 53 l
Carbon Monoxide, CO (mg/km): 44.2 mg/km

Performance

Maximum Speed (mph): 106 mph

Engine

Engine Code: 5WZ-TV
Engine Type: Diesel
Displacement (cc): 1499 cc
Bore x Stroke (mm x mm): 75 x 84.8 mm
Number Of Cylinders: 4 cylinder, in line
Fuel Injection System: Common rail diesel direct injection
Maximum Output (DIN hp): 100 DIN hp
Maximum Output (kW): 75 kW@rpm
Maximum Torque (Nm): 250 Nm

Transmission

Transmission Type: Manual
Drive: FWD

Suspension

Suspension Front: Pseudo Mac Pherson
Suspension Rear: Deformable crossbeam

Brakes

Brakes Front: Ventilated Disc
Brakes Rear: Disc

Weights & Towing Capacity

Gross Train Weight - Total (kg): 3390 kg
Gross Vehicle Weight (kg): 2390 kg
Kerb Weight / Unladen Weight (kg): 1408-1585 kg
Payload (kg): 1000 kg
Maximum Trailer Weight - Braked (kg): 1000 kg
Maximum Trailer Weight - Unbraked (kg): 730 kg
Gross Vehicle Weight - Front (kg): 1200 kg
Gross Vehicle Weight - Rear (kg): 1400 kg

Safety

Find peace of mind as you drive with Toyota T-Mate. Whether you’re reversing into a parking space or approaching a busy junction, T-Mate makes sure you're always in safe hands wherever you go.

Adjustable Speed Limiter (ASL)
Anti-tamper alarm
Automatic High Beam (AHB)
Cruise Control
Daytime running lights
Downhill Assist Control (DAC)
Driver Attention Alert
eCall emergency call system
Glass-breaking alarm sensors
Hill-start Assist Control (HAC)
Immobiliser
Intrusion Alarm
Lane Departure Alert (LDA) with Steering Control
Motion sensor alarm
Pre-Collision System with Pedestrian Detection
Rear parking sensors
Road Sign Assist (RSA)
Tyre Pressure Warning System (TPWS)
EcoLED headlamps

Panel bulkhead
Supplemental Restraint System (SRS) airbags - 6 airbags

Styling

Make a statement with elegant design elements and eye-catching details to make your vehicle stand out from the crowd.

Black door handles
Black door mirrors
Black front bumper
Black rear bumper
Privacy Glass - 30% (Smoke tint)
Short Antenna

4-spoke Urethane steering wheel
Black interior door handles
Open tray on passenger dashboard

Performance

From road-ready handling to efficient acceleration – discover what makes the Toyota driving performance so special.

Payload - 1000kg

Wheels

Choose from Toyota's selection of premium wheels to suit your driving style.

Full size Temporary spare wheel

Comfort

Sit back and relax in a car so comfortable that it feels like home – from ample space to stretch your legs to heating that keeps you warm when it's cold outside.

Auto headlights
Power-adjustable door mirrors
Electric heated door mirrors
Manually retractable door mirrors
Remote door lock
Two sliding side doors
Panel rear swing doors

2-seater front passenger bench
Audio switches on steering wheel
Boot light
Colour multi-information display
Driver & front passenger personal lights
Drivers armrest
Front room light
Lane Departure Alert (LDA) switch on lower driver dashboard
Manual air conditioning
Manually adjustable lumbar support on driver seat
Manually height-adjustable driver seat
Manually sliding front passenger seat
Pollen air filter
Power door lock
Speed Limiter Information
10" screen for multi-information display
Auto up and down power window passenger
Auto up and down power window driver
Open lower glovebox

Multimedia

Experience an intuitive multimedia system that seamlessly delivers real-time information, making it easier than ever for you to focus on the road ahead.

4 speakers
Digital Audio Broadcast (DAB)
Smartphone integration incl Apple CarPlay™ & Android Auto™
Front USB-C device charger
USB Type-C connector
Toyota Smart Connect with Smartphone integration including Apple CarPlay™ Multimedia system
Smartphone voice recognition on multimedia system
Multimedia - JBL ® Premium Sound System
10" HD multimedia display
