Proace City Active

Compact Panel Van

Proace City - Active - Compact Panel Van
from
£22,515.83 (Excl. VAT)
  • Smartphone integration incl Apple CarPlay™ & Android Auto™
  • 180° opening on rear wing doors
  • Two sliding side doors
46.3 - 49.5 mpg
149 - 161 g/km
1.5 Diesel (100hp)

POST https://dxp-webcarconfig.toyota-europe.com/v1/compare-v2/gb/en

  • Exterior Length (mm)
    4403 mm
  • Exterior Width (mm)
    1848 mm
  • Exterior Height (mm)
    1880 mm
  • Front Tread (mm)
    1548 mm
  • Rear Tread (mm)
    1568 mm
  • Overhang Front (mm)
    892 mm
  • Overhang Rear (mm)
    726 mm
  • Wheelbase (mm)
    2785 mm
  • Deck Length (mm)
    1817 mm
  • Deck Width (mm)
    1527 mm
  • Deck Height (mm)
    1200 mm
  • Load Volume With Smart Cargo (2 Seats, m³)
    3.8 m³
  • Loading Length With Smart Cargo (2 Seats, mm)
    3090 mm
  • Load Volume (m³)
    3.3 m³
  • Minimum Running Ground Clearance (mm)
    160 mm

  • CO2 Combined WLTP (g/km)
    149 g/km
  • Fuel Economy - Combined Min WLTP (mpg)
    46.3 mpg
  • Fuel Economy - Combined Max WLTP (mpg)
    49.5 mpg
  • CO2 Combined WLTP - Max (g/km)
    161 g/km
  • Hydrocarbons, THC & Nitrogen Oxides, NOx (mg/km)
    52.9 mg/km
  • Nitrogen Oxides, NOx (mg/km)
    48.8 mg/km
  • Sound Level Drive By (dB(A))
    68 dB(A)
  • Euro Class
    Euro 6 AQ
  • Fuel Tank Capacity
    53 l
  • Carbon Monoxide, CO (mg/km)
    54.7 mg/km
  • Engine Code
    5wz-tv
  • Displacement (cc)
    1499 cc
  • Bore x Stroke (mm x mm)
    75 x 84.8 mm
  • Number Of Cylinders
    4 Cylinder, In Line
  • Fuel Injection System
    Common rail diesel direct injection
  • Maximum Output (DIN hp)
    102 DIN hp
  • Maximum Output (kW@rpm)
    75/3750 kW@rpm
  • Maximum Torque (Nm@rpm)
    250/1750- Nm@rpm
  • Transmission Type
    Manual
  • Drive
    Fwd
  • Maximum Speed (mph)
    101 mph
  • Acceleration 0-62 (mph)
    11.5 seconds
  • Suspension Front
    Pseudo Mac Pherson
  • Suspension Rear
    Deformable crossbeam
  • Brakes Front
    Ventilated Disc
  • Brakes Rear
    Disc
  • Gross Train Weight - Total (kg)
    3570 kg
  • Gross Vehicle Weight - Total (kg)
    2370 kg
  • Kerb Weight / Unladen Weight (kg)
    1383-1606 kg
  • Payload (kg)
    1000 kg
  • Maximum Trailer Weight - Braked (kg)
    1200 kg
  • Maximum Trailer Weight - Unbraked (kg)
    720 kg
  • Gross Vehicle Weight - Front (kg)
    1200 kg
  • Gross Vehicle Weight - Rear (kg)
    1400 kg
  • Number of Seats
    2 seats
  • Interior length (mm)
    3090 mm
  • Interior Width (mm)
    1229 mm
  • Interior Height (mm)
    1200 mm

Interior
  • 2 speakers
  • Aux-in connector
  • Bluetooth® Connectivity
  • Digital Audio Broadcast (DAB)
  • USB connector
  • MyT Connected Services
Exterior
  • Cargo deck load hooks x 6
Interior
  • 0.5 litre bottle holder
  • Front bottle holders
  • In-floor storage box
  • Rubber floor in cargo area
  • Rubber Flooring
Exterior
  • 16" Steel wheels
  • Full size Temporary spare wheel
Exterior
  • 180° opening on rear wing doors
  • Auto headlights
  • Power-adjustable door mirrors
  • Electric heated door mirrors
  • Manually retractable door mirrors
  • Panel rear wing doors
  • Two sliding side doors
Interior
  • Anti-jam protection on power windows
  • Boot light
  • Driver & front passenger personal lights
  • Drivers armrest
  • Front power windows
  • Individual front passenger seat
  • Manual air conditioning
  • Manually adjustable lumbar support on driver seat
  • Manually height-adjustable driver seat
  • Manually reclining front passenger seat
  • Manually sliding front passenger seat
  • Mirror on driver sun visor
  • Pollen air filter
  • Electric front windows - One touch auto up & down function
  • 3.5" multi-information screen
Exterior
  • Anti-lock Braking System (ABS) with Electronic Brake force Distribution (EBD)
  • Brake Assist (BA)
  • Daytime running lights
  • Downhill Assist Control (DAC)
  • eCall emergency call system
  • Hill-start Assist Control (HAC)
  • Tyre Pressure Warning System (TPWS)
  • Vehicle Stability Control (VSC)
Interior
  • Adjustable rear headrests
  • Panel bulkhead
  • Supplemental Restraint System (SRS) airbags - 6 airbags
Exterior
  • Payload - 1000kg
Interior
  • Stop & Start System
Exterior
  • Black door handles
  • Black front bumper
  • Black rear bumper
  • Black upper front grille
  • Black door mirrors
Interior
  • Open tray on passenger dashboard
  • Satin chrome surround on multimedia display

PD - Active - Compact Panel Van
  • 2785
  • 4403
  • 1548
  • 1848
  • 1568
  • 1848
  • 1880

  • PD - Active - Compact Panel Van
  • PD - Active - Compact Panel Van
  • PD - Active - Compact Panel Van

POST https://dxp-webcarconfig.toyota-europe.com/v1/equipment-standard/gb/en?modelId=c9fe38ba-7298-4411-b85e-996dc0c9e6d1&carId=c6a0303c-bdbd-4dbb-9e9d-06af2d996eb1&carColourId=6db1c2bf-4b7f-47e4-980f-7c5996733b36

Read timed out

POST https://dxp-webcarconfig.toyota-europe.com/v1/equipment-optional/gb/en?modelId=c9fe38ba-7298-4411-b85e-996dc0c9e6d1&carId=c6a0303c-bdbd-4dbb-9e9d-06af2d996eb1&carColourId=6db1c2bf-4b7f-47e4-980f-7c5996733b36

Explore features by grade

Proace City

4 Options

  • Proace City - Active - Compact Panel Van

    Proace City Active

    Compact Panel Van
    • +
      Smartphone integration incl Apple CarPlay™ & Android Auto™
    • +
      180° opening on rear wing doors
    • +
      Two sliding side doors

    Select Engine


    £22,515.83 (Excl. VAT)

    6-speed Manual | Front Wheel Drive - FWD
    • Fuel Economy
      46.3 - 49.5 mpg
    • WLTP CO2
      149 - 161 g/km
  • Proace City - Icon - Compact Panel Van

    Proace City Icon

    Compact Panel Van
    • +
      180° opening on rear wing doors
    • +
      Two sliding side doors
    • +
      Reversing Camera

    Select Engine


    £23,411.67 (Excl. VAT)

    6-speed Manual | Front Wheel Drive - FWD
    • Fuel Economy
      46.3 - 49.5 mpg
    • WLTP CO2
      149 - 161 g/km
  • Proace City - Icon - Medium Panel Van

    Proace City Icon

    Medium Panel Van
    • +
      180° opening on rear wing doors
    • +
      Two sliding side doors
    • +
      Reversing Camera

    Select Engine


    £24,036.67 (Excl. VAT)

    6-speed Manual | Front Wheel Drive - FWD
    • Fuel Economy
      46.3 - 48.7 mpg
    • WLTP CO2
      151 - 161 g/km
  • Proace City - Design - Compact Panel Van

    Proace City Design

    Compact Panel Van
    • +
      Two sliding side doors
    • +
      Toyota Touch® 2 with Go Navigation
    • +
      Full size Temporary spare wheel

    Select Engine


    £25,361.67 (Excl. VAT)

    6-speed Manual | Front Wheel Drive - FWD
    • Fuel Economy
      43.4 - 47 mpg
    • WLTP CO2
      159 - 171 g/km

    £26,236.67 (Excl. VAT)

    8-speed Automatic | Front Wheel Drive - FWD
    • Fuel Economy
      43.4 - 47 mpg
    • WLTP CO2
      158 - 171 g/km
