Proace City Design
Features & Specs

Short Panel Van

Proace City - Design - Short Panel Van
Falcon Grey (Metallic Paint)

Starting from

29850.0

Financing From

/Month

*Representative Example and Core Finance Terms

Standard Engine

1.5 Diesel (100hp)

Warranty

Up to 10 years / 100,000 mile Toyota Warranty*

Proace City - Design - Short Panel Van

https://dxp-webcarconfig.toyota-europe.com/v1/compare-v2/gb/en

  • Front Tread (mm)
    1548 mm
  • Overhang Front (mm)
    892 mm
  • Overhang Rear (mm)
    726 mm
  • Exterior width (mm)
    1848 mm
  • Exterior length (mm)
    4403 mm
  • Rear Tread (mm)
    1568 mm
  • Wheelbase (mm)
    2785 mm
  • Exterior height (mm)
    1880 mm
  • Load volume (m³)
    3.3 m³
  • Deck height (mm)
    1200 mm
  • Loading length with Smart Cargo (2 seats, mm)
    3090 mm
  • Deck width (mm)
    1527 mm
  • Deck length (mm)
    1817 mm
  • Load volume with Smart Cargo (2 seats, m³)
    3.8 m³
  • Min. running ground clearance (mm)
    160 mm

  • Sound Level Drive by (dB(A))
    68 dB(A)
  • Hydrocarbons, THC & Nitrogen Oxides, NOx (mg/km)
    52.9 mg/km
  • Nitrogen Oxides, NOx (mg/km)
    48.8 mg/km
  • Fuel Economy - Combined Min WLTP (mpg)
    47.8 mpg
  • CO2 Combined WLTP (g/km)
    145 g/km
  • CO2 Combined WLTP - Max (g/km)
    156 g/km
  • Fuel tank capacity
    53 l
  • Carbon monoxide, CO (mg/km)
    54.7 mg/km
  • Fuel Economy - Combined Max WLTP (mpg)
    51.3 mpg
  • Euro class
    EURO 6 AQ
  • Bore x Stroke (mm x mm)
    75 x 84.8 mm
  • Maximum output (DIN hp)
    102 DIN hp
  • Engine Code
    5WZ-TV
  • Maximum torque (Nm@rpm)
    250/1750- Nm@rpm
  • Displacement (cc)
    1499 cc
  • Fuel Injection System
    Common rail diesel direct injection
  • Number of Cylinders
    4 CYLINDER, IN LINE
  • Maximum output (kW@rpm)
    75/3750 kW@rpm
  • Transmission Type
    Manual
  • Acceleration 0-62 (mph)
    11.5 seconds
  • Maximum Speed (mph)
    101 mph
  • Suspension Front
    Pseudo Mac Pherson
  • Suspension Rear
    Deformable crossbeam
  • Brakes Front
    Ventilated Disc
  • Brakes Rear
    Disc
  • Payload (kg)
    1000 kg
  • Maximum Trailer Weight - Unbraked (kg)
    730 kg
  • Maximum Trailer Weight - Braked (kg)
    1200 kg
  • Kerb Weight / Unladen Weight (kg)
    1404-1627 kg
  • Gross Vehicle Weight - Total (kg)
    2390 kg
  • Gross Train Weight - Total (kg)
    3590 kg
  • Gross Vehicle Weight - Front (kg)
    1200 kg
  • Gross Vehicle Weight - Rear (kg)
    1400 kg
  • Number of Seats
    3 seats
  • Interior height (mm)
    1200 mm
  • Interior width (mm)
    1229 mm
  • Interior length (mm)
    3090 mm

Legend
  • Standard
  • Optional
  • Not applicable
  • Promotion
  • Exception
  • Available in optional pack
Interior
  • Toyota Touch® 2 with Go Navigation
  • USB connector
  • 2 speakers
  • Aux-in connector
  • Bluetooth® Connectivity
  • Digital Audio Broadcast (DAB)
  • Wi-Fi connectivity
  • Smartphone integration incl Apple CarPlay™ & Android Auto™
  • MyT Connected Services
Exterior
  • Cargo deck load hooks x 6
Interior
  • 0.5 litre bottle holder
  • Front bottle holders
  • Smart Cargo
  • In-floor storage box
  • Rubber floor in cargo area
Exterior
  • 16" Alloy wheels (5-double-spoke)
  • Full size Temporary spare wheel
Exterior
  • 180° opening on rear wing doors
  • Auto headlights
  • Auto wipers
  • Power-adjustable door mirrors
  • Electric heated door mirrors
  • Panel rear wing doors
  • Power retractable door mirrors
  • Two sliding side doors
Interior
  • Manual air conditioning
  • 2-seater front passenger bench
  • Anti-jam protection on power windows
  • Audio switches on steering wheel
  • Boot light
  • Driver & front passenger personal lights
  • Dynamic guide lines on Reversing Camera
  • Front power windows
  • Lane Departure Alert (LDA) switch on lower driver dashboard
  • Manually height-adjustable driver seat
  • Manually reclining front passenger seat
  • Manually sliding front passenger seat
  • Mirror on driver sun visor
  • Pollen air filter
  • Electric front windows - One touch auto up & down function
  • 3.5" multi-information screen
Exterior
  • Front parking sensors
  • Rear parking sensors
  • Reversing Camera
  • Pre-Collision System
  • Lane Departure Alert (LDA) with Steering Control
  • Road Sign Assist (RSA)
  • Adjustable Speed Limiter (ASL)
  • Anti-lock Braking System (ABS) with Electronic Brake force Distribution (EBD)
  • Anti-tamper alarm
  • Brake Assist (BA)
  • Cruise Control
  • Daytime running lights
  • Downhill Assist Control (DAC)
  • Driver Attention Alert
  • eCall emergency call system
  • Front fog lights
  • Glass-breaking alarm sensors
  • Hill-start Assist Control (HAC)
  • Immobiliser
  • Intrusion Alarm
  • Motion sensor alarm
  • Tyre Pressure Warning System (TPWS)
  • Vehicle Stability Control (VSC)
Interior
  • Supplemental Restraint System (SRS) airbags - 6 airbags
  • Panel bulkhead
Exterior
  • Payload - 1000kg
Interior
  • Stop & Start System
Exterior
  • Body-coloured protection moulding on side doors
Exterior
  • Black upper front grille
  • Body-coloured door handles
  • Body-coloured front bumper
  • Body-coloured rear bumper
  • Body-coloured rail cover on side sliding door
  • Gloss Black door mirrors
Interior
  • Electronic parking brake
  • Open tray on passenger dashboard

  • 2785
  • 4403
  • 1548
  • 1848
  • 1568
  • 1848
  • 1880
  • Exterior length (mm) 4403 mm
  • Exterior width (mm) 1848 mm
  • Exterior height (mm) 1880 mm
  • Front Tread (mm) 1548 mm
  • Rear Tread (mm) 1568 mm
  • Overhang Front (mm) 892 mm
  • Overhang Rear (mm) 726 mm
  • Wheelbase (mm) 2785 mm

  • interior-image0
  • interior-image1
  • interior-image2
  • Number of Seats 3 seats
  • Interior length (mm) 3090 mm
  • Interior width (mm) 1229 mm
  • Interior height (mm) 1200 mm

  • Deck length (mm) 1817 mm
  • Deck width (mm) 1527 mm
  • Deck height (mm) 1200 mm
  • Load volume with Smart Cargo (2 seats, m³) 3.8 m³
  • Loading length with Smart Cargo (2 seats, mm) 3090 mm
  • Load volume (m³) 3.3 m³

https://dxp-webcarconfig.toyota-europe.com/v1/equipment-standard/gb/en?modelId=c9fe38ba-7298-4411-b85e-996dc0c9e6d1&carId=4849fc01-a2ae-4323-9a08-6976a40129a7&carColourId=2b39434c-61ef-4c79-a9ea-0faca5819b96&contentViewMode=list

Read timed out

https://dxp-webcarconfig.toyota-europe.com/v1/equipment-optional/gb/en?modelId=c9fe38ba-7298-4411-b85e-996dc0c9e6d1&carId=4849fc01-a2ae-4323-9a08-6976a40129a7&carColourId=2b39434c-61ef-4c79-a9ea-0faca5819b96

Ready to start? Choose your engine
Ready to start? Choose your engine

3 Options

3 Options

  • 1.5 Diesel (100hp) Diesel

    6-speed Manual | Front Wheel Drive - FWD

    More details Collapse

    47.8 - 51.3 (mpg)

    Fuel Economy

    144 - 156 (g/km)

    WLTP CO2

    More details Collapse

  • 1.5 Diesel (130hp) Diesel

    6-speed Manual | Front Wheel Drive - FWD

    More details Collapse

    47 - 50.4 (mpg)

    Fuel Economy

    146 - 157 (g/km)

    WLTP CO2

    More details Collapse

  • 1.5 Diesel (130hp) Diesel

    8-speed Automatic | Front Wheel Drive - FWD

    More details Collapse

    44.8 - 48.7 (mpg)

    Fuel Economy

    153 - 164 (g/km)

    WLTP CO2

    More details Collapse

Choose your Proace City
Choose your Proace City

6 Options

6 Options

  • Active

    Short Panel Van

    from 25450.0

    • Two sliding side doors
    • 180° opening on rear wing doors
    • Panel bulkhead
    • Full size Temporary spare wheel
    • Manual air conditioning
    • Auto headlights
    • Electric front windows - One touch auto up & down function
    • Electric heated door mirrors

    More details Collapse

  • Icon

    Short Panel Van

    from 27550.0

    • Smartphone integration incl Apple CarPlay™ & Android Auto™
    • Two sliding side doors
    • Reversing Camera
    • Smart Cargo
    • Electronic parking brake
    • Front parking sensors
    • Rear parking sensors
    • 2-seater front passenger bench

    More details Collapse

  • Icon

    Long Panel Van

    from 28300.0

    • Smartphone integration incl Apple CarPlay™ & Android Auto™
    • Two sliding side doors
    • Reversing Camera
    • Smart Cargo
    • Electronic parking brake
    • Front parking sensors
    • Rear parking sensors
    • 2-seater front passenger bench

    More details Collapse

  • Design

    Short Panel Van

    from 29850.0

    • 16" Alloy wheels (5-double-spoke)
    • Pre-Collision System
    • Two sliding side doors
    • Road Sign Assist (RSA)
    • Toyota Touch® 2 with Go Navigation
    • Immobiliser
    • Intrusion Alarm
    • Lane Departure Alert (LDA) with Steering Control

    More details Collapse

  • Design

    Short Panel Van

    from 30900.0

    • 16" Alloy wheels (5-double-spoke)
    • Pre-Collision System
    • Two sliding side doors
    • Road Sign Assist (RSA)
    • Toyota Touch® 2 with Go Navigation
    • Immobiliser
    • Intrusion Alarm
    • Lane Departure Alert (LDA) with Steering Control

    More details Collapse

  • Design

    Short Panel Van

    from 31950.0

    • 16" Alloy wheels (5-double-spoke)
    • Pre-Collision System
    • Two sliding side doors
    • Road Sign Assist (RSA)
    • Toyota Touch® 2 with Go Navigation
    • Immobiliser
    • Intrusion Alarm
    • Lane Departure Alert (LDA) with Steering Control

    More details Collapse
