Everything in detail

Proace City Verso EV Icon specifications

View specifications

Space and Room

High-quality fabrics and soft ornamentation add pleasingly human touches to your interior, transforming the open cabin into an inviting space where everyone feels comfortable.

Exterior dimensions

Exterior Length (mm): 4403 mm
Exterior Width (mm): 1848 mm
Exterior Height (mm): 1880 mm
Front Tread (mm): 1553 mm
Rear Tread (mm): 1567 mm
Overhang Front (mm): 890 mm
Overhang Rear (mm): 726 mm
Wheelbase (mm): 2785 mm
Number of Doors: 5

Interior dimensions

Number of Seats: 5 seats
Interior length (mm): 3300 mm
Interior Width (mm): 1465 mm
Interior Height (mm): 1200 mm

Luggage volume

Luggage Capacity (Laden To Roof): 1355 litres
5 Seat Mode (Laden To Tonneau Cover): 597 litres
5 Seat Mode (Laden To Roof): 983 litres
Load Volume (m³): 0.775 m³

Electric Engine

Electric Engine description

Environmental Performance

CO2 Combined (g/km): 0.00 g/km
Fuel Economy - Combined WLTP (l/100km): 0.00 l/100 km
Electric Range – Combined WLTP (miles): 211.89 miles
Electric Consumption (Wh/km): 182 Wh/km
Electric Consumption - Max (Wh/km): 217 Wh/km
Power Consumption WLTP (kWh/100 miles): 29.3 kWh/100 miles
Sound Level Drive By (dB(A)): 68.0 dB(A)
Euro Class: AX
Pure Electric Range – City - Max (miles): 242.96 miles
Pure Electric Range – City (miles): 287.07 miles

Performance

Maximum Speed (mph): 82 mph

Engine

Total System Output (kW): 100 kW
Engine Code: 2WZ-EV
Maximum Output (DIN hp): 136 DIN hp
Hybrid Vehicle Battery: Type: Lfp/gr
Hybrid Vehicle Battery: Capacity Ah (hr): 147 Ah
Battery Capacity (Usable, kWh): 50 kWh
10-80% Charging Time (mins) DC Charger: 30 mins (approx)
0-100% Charging Time AC (hours): 0.5 hours (approx)
Battery Charging Time (hours) AC Charger: 0.5 hours (approx)
Maximum Charging Power AC (kW): 11 kW
Battery Capacity (Ah): 147 Ah
Battery Capacity (kWh): 52 kWh
Battery Energy (kWh): 50 kWh
Battery Weight (kg): 340 kg

Transmission

Transmission Type: Automatic
Drive: FWD

Suspension

Suspension Front: Pseudo mc pherson
Suspension Rear: Deformable crossbeam

Brakes

Brakes Front: Disc
Brakes Rear: Ventilated Disc

Weights & Towing Capacity

Gross Train Weight - Total (kg): 3110 kg
Gross Vehicle Weight (kg): 2360 kg
Kerb Weight / Unladen Weight (kg): 1736-1928 kg
Maximum Trailer Weight - Braked (kg): 750 kg
Maximum Trailer Weight - Unbraked (kg): 750 kg
Gross Vehicle Weight - Front (kg): 1200 kg
Gross Vehicle Weight - Rear (kg): 1380 kg

Safety

Find peace of mind as you drive with Toyota T-Mate. Whether you’re reversing into a parking space or approaching a busy junction, T-Mate makes sure you're always in safe hands wherever you go.

eCall emergency call system
Pre-Collision System with Pedestrian Detection
Lane Departure Alert with Steering Control
Road Sign Assist (RSA)
Adjustable Speed Limiter
Cruise Control
Hill-start Assist Control
Tyre Pressure Warning System
Automatic High Beam
Daytime running lights
EcoLED headlamps
Rear parking sensors
Anti-tamper alarm
Glass-breaking alarm sensors
Immobiliser
Intrusion Alarm
Motion sensor alarm

Supplemental Restraint System airbags - 6 airbags
SRS Curtain shield airbags
ISOFIX child restraint system
Front passenger seat foldable backrest

Styling

Make a statement with elegant design elements and eye-catching details to make your vehicle stand out from the crowd.

Privacy Glass - 30% (Smoke tint)
Black door handles
Black door mirrors
Black front bumper
Black rear bumper

4-spoke Urethane steering wheel
Open tray on passenger dashboard
Black interior door handles

Wheels

Choose from Toyota's selection of premium wheels to suit your driving style.

Tyre Repair Kit

Comfort

Sit back and relax in a car so comfortable that it feels like home – from ample space to stretch your legs to heating that keeps you warm when it's cold outside.

Auto headlights
Power-adjustable door mirrors
Electric heated door mirrors
Manually retractable door mirrors
Two sliding side doors
Two tilting side windows on 2nd row
Two fixed side windows on 3rd row
Rear tailgate with fixed window
Rear tailgate
Remote door lock

Colour multi-information display
10" screen for multi-information display
Speed Limiter Information
Audio switches on steering wheel
Manual air conditioning
Pollen air filter
Manual day/night rear-view mirror
Power door lock
Rear window defogger
Lane Departure Alert switch on lower driver dashboard
Auto up and down power window passenger
Auto up and down power window driver
Boot light
Centre room light
Driver & front passenger personal lights
Front room light
Rear passenger room light
Drivers armrest
Manually adjustable lumbar support on driver seat
Manually height-adjustable driver seat
1/3 : 2/3 split-folding 2nd row rear seats
2nd row 3-seat rear bench
Flat-floor folding 2nd row rear bench
Retractable 2nd row rear bench
Power child safety door lock
Electronic parking brake

Multimedia

Experience an intuitive multimedia system that seamlessly delivers real-time information, making it easier than ever for you to focus on the road ahead.

Toyota Smart Connect with Smartphone integration including Apple CarPlay™ Multimedia system
10" HD multimedia display
Toyota Touch® 2 with Go Navigation
Smartphone integration incl Apple CarPlay™ & Android Auto™
Multimedia - JBL ® Premium Sound System
6 speakers
Digital Audio Broadcast
Voice recognition
Front USB-C device charger
USB Type-C connector
