Everything in detail

Corolla Touring Sports Commercial specifications

View specifications

Space and Room

High-quality fabrics and soft ornamentation add pleasingly human touches to your interior, transforming the open cabin into an inviting space where everyone feels comfortable.

Exterior dimensions

Exterior Length (mm): 4650 mm
Exterior Width (mm): 1790 mm
Exterior Height (mm): 1460 mm
Front Tread (mm): 1530 mm
Rear Tread (mm): 1530 mm
Overhang Front (mm): 935 mm
Overhang Rear (mm): 1015 mm
Wheelbase (mm): 2700 mm

Interior dimensions

Number of Seats: 2 seats
Interior length (mm): 1855 mm
Interior Width (mm): 1510 mm
Interior Height (mm): 1155 mm

Luggage volume

2 Seat Mode (Laden To Roof): 1606 litres
Load Volume (m³): 0.596 m³
Luggage Capacity VDA (Rear Seats Up, Laden To Tonneau Cover) litres: 596 litres

Engine

Drive with pure emotion, powered by a high-performance engine that helps you take on any journey with confidence.

Environmental Performance

CO2 Combined WLTP (g/km): 111 g/km
CO2 Combined - WLTP (g/km): 100 g/km
Fuel Economy - Combined WLTP (mpg): 64.1 mpg
Fuel Economy - Combined Min WLTP (mpg): 57.6 mpg
Fuel Economy Combined WLTP (l/100 km): 4.4 l/100 km
Carbon Monoxide, CO (mg/km): 95.5 mg/km
Hydrocarbons, THC (mg/km): 15.2 mg/km
Hydrocarbons, NMHC (mg/km): 12.7 mg/km
Nitrogen Oxides, NOx (mg/km): 3.5 mg/km
Sound Level Drive By (dB(A)): 63 dB(A)
Euro Class: EURO 6 EB
Recommended Fuel Grade: 91 or more (octane)
Fuel Tank Capacity (l): 43 l

Performance

Maximum Speed (mph): 111 mph
Acceleration 0-62 (mph): 9.4 seconds

Engine

Total System Output (DIN hp): 140 DIN hp
Total System Output (kW): 103 kW
Engine Code: 2ZR-FXE
Displacement (cc): 1798 cc
Bore x Stroke (mm x mm): 80.5 x 88.3 mm
Compression Ratio: 13.048:1
Engine Layout & Number Of Cylinders: 4 Cylinder, In Line
Valve Mechanism: 16-valve DOHC, chain drive with dual VVT-i
Fuel Injection System: Fuel injection
Maximum Output (DIN hp): 140 DIN hp
Maximum Output (kW@rpm): 103/5200 kW@rpm
Maximum Torque (Nm@rpm): 185 Nm
Hybrid Vehicle Battery: Type: Lithium-ion
Hybrid Vehicle Battery: Capacity Ah (hr): 4.08 Ah
Battery Capacity (Ah): 4.08 Ah
Electric Front Motor: Type: Permanent magnet synchronous motor
Electric Front Motor: Maximum Output (kW): 70 kW
Electric Front Motor: Maximum Torque (Nm): 185 Nm

Transmission

Transmission Type: Automatic

Suspension

Suspension Front: Macpherson strut
Suspension Rear: Double wishbone

Brakes

Brakes Front: Ventilated disc 1-cylinder
Brakes Rear: Solid disc 1-cylinder

Weights & Towing Capacity

Gross Train Weight - Total (kg): 2585 kg
Gross Vehicle Weight (kg): 1835 kg
Kerb Weight / Unladen Weight (kg): 1410-1415 kg
Maximum Trailer Weight - Braked (kg): 750 kg
Maximum Trailer Weight - Unbraked (kg): 450 kg
Gross Vehicle Weight - Front (kg): 1050 kg
Gross Vehicle Weight - Rear (kg): 970 kg

Safety

Find peace of mind as you drive with Toyota T-Mate. Whether you’re reversing into a parking space or approaching a busy junction, T-Mate makes sure you're always in safe hands wherever you go.

Adaptive Automatic High Beam (AHB)
Adjustable Speed Limiter (ASL)
Driver Attention Alert
eCall emergency call system
Emergency Brake-light Signal (EBS)
Lane Departure Alert (LDA) with Steering Control
Lane Trace Assist (LTA)
LED Daytime running lights
LED Front fog lights
LED Multi-reflector headlights
Manual headlight levelling
Reversing Camera
Road Sign Assist (RSA)
Tyre Pressure Warning System (TPWS)
Vehicle Stability Control (VSC)
Emergency Steering Assist
Intelligent Adaptive Cruise Control (iACC)
Acoustic Vehicle Alert System
Driver Monitoring Camera
Front-to-front Oncoming Car & Motorbike daytime detection
Acceleration Suppression at low speed
Toyota Safety Sense with Over-the-Air Updates
Pre-Collision System - with Intersection detection
Proactive Driving Assist (PDA)
Pre-Collision System

Front seat belt reminder
Passenger airbag on/off-switch
Supplemental Restraint System (SRS) airbags - 7 airbags
Rear seat reminder

Styling

Make a statement with elegant design elements and eye-catching details to make your vehicle stand out from the crowd.

B - Pillar in Black
Black door mirrors
Black lower front grille
Black surround on lower front grille
Black window frame
Body-coloured door handles
Body-coloured rear bumper
Body-coloured rear spoiler
Body-coloured shark-fin antenna
Meshed lower front grille
Gloss black diffuser
Gloss black upper front grille

Black interior door handles
Black stitching on steering wheel
Fabric armrest
Satin chrome gear shift surround on centre console
Satin chrome insert on dashboard
Satin chrome surround on speedometer
Soft-touch texture on upper dashboard
Door scuff plates
3-spoke synthetic leather steering wheel

Performance

From road-ready handling to efficient acceleration – discover what makes the Toyota driving performance so special.

Body-coloured front spoiler

Wheels

Choose from Toyota's selection of premium wheels to suit your driving style.

Tyre Repair Kit (TRK)

Comfort

Sit back and relax in a car so comfortable that it feels like home – from ample space to stretch your legs to heating that keeps you warm when it's cold outside.

Auto headlights
Power-adjustable door mirrors
Electric heated door mirrors
Manually retractable door mirrors
Remote door lock

12v power outlet - Boot
12v power outlet - Front
7" Digital Combimeter
Adaptive Cruise Control (ACC) switch on steering wheel
Adjustable Speed Limiter (ASL) switch on steering wheel
Anti-jam protection on power windows
Assist grips - Driver
Audio switches on steering wheel
Black armrest on centre console box
Boot light
Child safety door lock
Clean air filter
Colour multi-information display
Driver & front passenger personal LED lights
Dual-zone automatic air conditioning
Auto up & down function on power windows
Electronic parking brake
Heated driver & front passenger seats
Key reminder warning
Lane Departure Alert (LDA) switch on steering wheel
Light on driver sun visor
Light on passenger sun visor
Manual day/night rear-view mirror
Manual telescopic steering wheel
Manual tilt steering wheel
Manually height-adjustable driver seat
Manually height-adjustable front passenger seat
Manually sliding driver seat
Manually sliding front passenger seat
Mirror on driver sun visor
Mirror on passenger sun visor
Multi-info switches on steering wheel
Noise reduction layer on windscreen
Pollen air filter
Power door lock
Power passenger window lock
Power-adjustable lumbar support on driver seat
Push-button start
Rear passenger personal lights
Rear window defogger
Rear window wiper
Reversing Camera display in multimedia system
Sliding central armrest
Static guide lines on Reversing Camera
Telephone switches on steering wheel
UV-filter on driver & front passenger windows
UV-filter on rear windows
Voice recognition switch on steering wheel

Multimedia

Experience an intuitive multimedia system that seamlessly delivers real-time information, making it easier than ever for you to focus on the road ahead.

6 speakers
8" multimedia system
Bluetooth® Connectivity
Digital Audio Broadcast (DAB)
Connected Services
USB connector
Voice recognition
Smartphone integration incl Apple CarPlay™ & Android Auto™
Smart Voice Assist
Cloud Navigation
Toyota Smart Connect with Smartphone integration incl Apple CarPlay™

Storage

This fantastic interior space offers plenty of room for all ‒ including ample legroom to comfortably stretch your legs, and a spacious boot to fit everything you’ll need.

Black roof rails
