Everything in detail

All-New Hilux Active specifications

View specifications

Space and Room

High-quality fabrics and soft ornamentation add pleasingly human touches to your interior, transforming the open cabin into an inviting space where everyone feels comfortable.

Exterior dimensions

Exterior Length (mm): 5320 mm
Exterior Width (mm): 1855 mm
Exterior Height (mm): 1865 mm
Front Tread (mm): 1540 mm
Rear Tread (mm): 1550 mm
Overhang Front (mm): 990 mm
Overhang Rear (mm): 1245 mm
Wheelbase (mm): 3085 mm

Interior dimensions

Number of Seats: 5 seats
Interior length (mm): 1676 mm
Interior Width (mm): 1438 mm
Interior Height (mm): 1165 mm

Luggage volume

Deck Length (mm): 1555 mm
Deck Width (mm): 1540 mm
Deck Height (mm): 480 mm

Engine

Drive with pure emotion, powered by a high-performance engine that helps you take on any journey with confidence.

Environmental Performance

WLTP CO2: 0 - 255 g/km
Fuel Economy: 27.6 - 29.1 mpg
Fuel Economy - Combined WLTP (l/100km): 9.7 l/100 km
Carbon Monoxide, CO (mg/km): 33.6 mg/km
Hydrocarbons, THC & Nitrogen Oxides, NOx (mg/km): 30 mg/km
Nitrogen Oxides, NOx (mg/km): 23.1 mg/km
Sound Level Drive By (dB(A)): 69.0 dB(A)
Euro Class: EURO 6 EB
Recommended Fuel Grade: 48 or more(cetane)
Fuel Tank Capacity (l): 80 l
CO2 Combined WLTP (g/km) - Normal: 255 g/km
Fuel Combined WLTP (km/l): 10.3 km/l

Performance

Maximum Speed (mph): 109 mph

Engine

Engine Code: 1GD-FTV
Engine Type: Diesel miled highbrid
Displacement (cc): 2755 cc
Bore x Stroke (mm x mm): 92.0 x 103.60 mm
Compression Ratio: 15.6:1
Engine Layout & Number Of Cylinders: 4 cylinder, in line
Valve Mechanism: DOHC 16-Valve
Fuel Injection System: Fuel injection
Maximum Output (DIN hp): 204 DIN hp
Hybrid Vehicle Battery: Type: lithium-ion
Hybrid Vehicle Battery: Capacity Ah (hr): 4.3 Ah
Maximum Torque (Nm): 500 Nm
Battery Capacity (Ah): 4.3 Ah
Electric Front Motor: Type: permanent magnet synchronous motor

Transmission

Transmission Type: Automatic
Gearbox: 6 Speed Automatic
Drive: 4WD

Brakes

Brakes Front: Ventilated disc 4-cylinder
Brakes Rear: Drum

Weights & Towing Capacity

Gross Train Weight - Total (kg): 6300 kg
Gross Vehicle Weight (kg): 3210 kg
Kerb Weight / Unladen Weight (kg): 2175-2360 kg
Payload (kg): 1035 kg
Maximum Trailer Weight - Braked (kg): 3500 kg
Maximum Trailer Weight - Unbraked (kg): 750 kg
Gross Vehicle Weight - Front (kg): 1490 kg
Gross Vehicle Weight - Rear (kg): 1920 kg

Safety

Find peace of mind as you drive with Toyota T-Mate. Whether you’re reversing into a parking space or approaching a busy junction, T-Mate makes sure you're always in safe hands wherever you go.

Anti-lock Braking System with Electronic Brake force Distribution
Automatic High Beam
Blind Spot Monitor
Brake Assist (BA)
eCall emergency call system
Full-range Adaptive Cruise Control
Hill-start Assist Control
Immobiliser
Lane Trace Assist
LED Dual-beam Projector headlights
Pre-Collision System
Reversing Camera
Road Sign Assist
Traction Control
Trailer Sway Control
Tyre Pressure Warning System
Vehicle Stability Control (VSC)
Safe Exit Assist
Front parking sensors with automatic object braking
Rear parking sensors with automatic object & car braking
Driver Monitoring Camera
Automatic Rear Flashing Hazard Lights
Toyota Safety Sense
Key-lockable cargo deck
Turning signal (halogen)
Rear combination lights
Rear fog lights
Rear Vehicle Alert Indicator
Manual headlight levelling

Front seat belt reminder
ISOFIX child restraint system
Passenger airbag on/off-switch
Rear seat belt reminder
Driver & passenger central airbag
Rear seats occupant detection sensor
Front curtainshield airbag
Rear curtainshield airbag
Passenger seat occupant detection sensor
Light reminder warning
Horn alarm
Driver & passenger front airbag
Driver knee airbag
Airbags - Driver & passenger side

Styling

Make a statement with elegant design elements and eye-catching details to make your vehicle stand out from the crowd.

Black front bumper
Shark-fin antenna
Gloss black door handles
Gloss black door mirrors
Honeycomb upper front grille
Black front under-run
Body-coloured 'TOYOTA' logo on tailgate
Black plastic lower front grille

Silver deco line on upper dashboard
3-spoke Urethane steering wheel
Black upper dashboard
Open tray on passenger dashboard
Rear armrest
PVC gear shift knob
Dark grey central console
Black interior door handles

Performance

From road-ready handling to efficient acceleration – discover what makes the Toyota driving performance so special.

4x4 - Rear Differential Lock
Pitch & Bounce control
Double wishbone front suspension
Leaf spring rear suspension
Auto Limited Slip Differential (LSD)

Wheels

Choose from Toyota's selection of premium wheels to suit your driving style.

Full size Temporary spare wheel

Comfort

Sit back and relax in a car so comfortable that it feels like home – from ample space to stretch your legs to heating that keeps you warm when it's cold outside.

Power-adjustable door mirrors
Electric heated door mirrors
Power retractable door mirrors
Rear step on bumper
Smartphone remote hazard lights system
Smartphone remote door lock
Remote door lock with smart key
Rear side step

60:40 split tip-up rear bench
7" Digital Combimeter
Digital speedometer (mph)
ECO-driving Indicator
Electric Power Steering
Manual air conditioning
Manual day/night rear-view mirror
Manual telescopic steering wheel
Manual tilt steering wheel
Manually height-adjustable driver seat
Push-button start
Telephone switches on steering wheel
Voice recognition switch on steering wheel
Washer fluid level warning
Multimedia switches on steering wheel

Multimedia

Experience an intuitive multimedia system that seamlessly delivers real-time information, making it easier than ever for you to focus on the road ahead.

4 speakers
Digital Audio Broadcast
9" Multimedia system
Toyota Touch® 3 multimedia system
Smartphone Integration (wireless Apple CarPlay and wireless Android Auto
Microphone (1)
Front USB-C connectors x 2
